Summary of 292161-7 TE Connectivity AMP CT 2mm Vertical Connector

For design engineers and procurement specialists looking to streamline PCB connectivity, the 292161-7 vertical header by TE Connectivity AMP Connectors stands out as a reliable solution within the AMP CT Series. As a wire-to-board connector, this product is engineered for compact applications, offering a footprint with a 2.00mm (0.079 inch) centerline and supporting seven distinct positions in a single row. Its vertical orientation and through-hole solder mounting make it ideal for robust board-to-cable or board-to-board interconnections. The AMP CT 2mm Post Header Assembly’s partially shrouded tin-plated contacts enhance both durability and signal integrity, supporting widespread adoption in designs where both space efficiency and performance are top priorities.

Physical and Electrical Characteristics of 292161-7 AMP CT Family

The 292161-7 header highlights several essential technical features relevant for engineers. Mechanically, the single-row, seven-position layout maximizes board real estate utilization while maintaining clear trace routing beneath the connector. The vertical mounting simplifies cable-to-board alignment, which is a significant advantage during automated assembly or field servicing. Tin (Sn) plating on contacts assures stable electrical conduction and corrosion resistance, particularly in standard environments. The partially shrouded design provides mechanical protection against accidental contact, supporting safety and longevity.

Electrically, the 2mm pitch has proven to be a sweet spot for balancing compactness with manufacturability, preventing risks of solder bridging and facilitating reproducible assembly yield. Through-hole soldering ensures robust mechanical retention—critical for applications subject to repetitive mating cycles or vibration. Engineers benefit from standardized mating with the AMP CT connector system, enabling compatibility with a broad range of cable assemblies and complementary contacts produced within the series.

Use Cases for 292161-7 AMP CT Family

Given the attributes of the 292161-7 AMP CT header, it is well suited for a myriad of wire-to-board interfacing tasks. Typical domains include consumer electronics, industrial controls, and instrumentation where compact, reliable wire termination is required on the PCB. For example, controllers requiring multi-signal cable harnesses, compact input/output modules, or portable instrumentation benefit from the header’s combination of density and mechanical security. Designers faced with spatial constraints or modular I/O requirements will appreciate the efficient pin configuration and secure through-hole anchoring. In environments where connector accessibility and straightforward vertical mating are important, this header offers distinct installation and maintenance advantages.

Regulatory and Environmental Information for 292161-7 AMP CT Family

Regulatory compliance is pivotal in today’s global engineering landscape. The 292161-7 AMP CT header is verified to meet EU RoHS (Restriction of Hazardous Substances) and ELV (End-of-Life Vehicles) directives, featuring maximum allowable concentrations for substances such as lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE, or qualifying for specific exemptions. Additionally, the product’s documentation addresses REACH requirements concerning SVHC (Substances of Very High Concern) as defined by the European Chemicals Agency, supporting safe use in regulated environments. While finished equipment fitted with this connector will bear appropriate CE markings under EU directives, components such as this header may not directly display CE marks but are nevertheless documented for compliance.

Alternative or Substitute Options for 292161-7 AMP CT Family

Engineers facing obsolescence planning or supply risk mitigation often seek alternative connector models. Within the AMP CT series from TE Connectivity, several headers and complementary connectors offer functional parity in terms of pitch, row configuration, and mounting style. Models such as the CT 2mm Header Assembly: Right Angle accommodate PCBs where vertical clearance limits require horizontal orientation, while various other single-row headers in the 2mm pitch family may be substituted depending on specific I/O requirements. It is critical to validate pin count, shrouding, and mounting style compatibility before making replacement selections. Referencing closely-related AMP CT models and consulting TE Connectivity's product selection guides ensures system-level interoperability and qualification.

Associated Parts and Integration Solutions for 292161-7 AMP CT Family

System integration speeds up when supporting cable assemblies and contacts are available off-the-shelf. Compatible parts, including the CT 7P 300MM cable assembly and common termination contacts and housings, facilitate reliable mating and straightforward harness design. Engineers can design wire harnesses using AMP CT housing options and specification-matched contact systems to complete the interconnection chain. Attention to complementary hardware—including receptacles, locking accessories, and strain-relief features—further ensures durability and compliance in varied applications. Integrating with these auxiliary elements minimizes the risk of mismatched components and supports standardized manufacturing workflows.

Accessible Technical Documents for 292161-7 AMP CT Family

Comprehensive technical documentation aids design and validation. TE Connectivity provides detailed product drawings, 2D DXF and 3D CAD files (IGES, STEP formats), and workmanship specifications for the 292161-7 AMP CT header. These resources support precise PCB layout planning, automated design workflows, and verification during prototype or production phases. Ready access to dimensional and specification data is essential for cross-functional engineering teams coordinating mechanical, electrical, and compliance reviews.

Conclusion

: Evaluating 292161-7 TE Connectivity AMP CT Series in Engineering Design

For procurement professionals and design engineers, the 292161-7 AMP CT 2mm Vertical Header by TE Connectivity presents a proven connector solution tailored for modern, space-constrained electronic assemblies. Its robust mechanical design, compliance with international environmental directives, and extensive series compatibility make it an optimal choice for wire-to-board applications demanding reliability and supply chain flexibility. Coupled with ready-to-integrate cable assemblies, extensive documentation, and alternative model support, this connector serves as a cornerstone for quality interconnection in today’s electronic systems.
