IDT, Integrated Device Technology Inc 74ALVCH32245BF

Mfr. Part

74ALVCH32245BF

Manufacturer

Renesas Electronics Corporation

Y-IC is a quality distributor of Renesas. We deliver genuine products, fast service, and expert support to help you succeed.

Detailed Description

32-bit non-inverting bus transceiver, configured as four 8-bit segments. Operates at 2.7 to 3.6 V, delivers up to 24 mA per output, and supports 3-state outputs for bus sharing. Industrial temperature range from -40 to +85 C. Packaged in 96-ball CABGA/LFBGA, supplier device package 96-CABGA (13.5 x 5.5 mm). RoHS non-compliant.

Key Features

32-bit bus width split into 4 x 8-bit elements for flexible design

Non-inverting transceiver logic for clean, direct signal transfer

3-state outputs for easy bus isolation and multiplexing

High drive strength ±24 mA per output

Wide supply range 2.7 to 3.6 V

Surface-mount BGA footprint for compact layouts

Industrial temperature rating -40 to +85 C

Part of the 74ALVCH high-speed, low-voltage CMOS logic series

Key Advantages

Moves data in both directions between two buses with simple control

Preserves signal polarity, reducing logic complexity

Strong drive capability supports longer traces and heavier loads

3-state outputs minimize bus contention and allow shared lines

Compact BGA reduces PCB area and can improve signal integrity

Low-voltage CMOS helps lower power vs. older 5 V families

Packaging

Device type: 96-CABGA and 96-LFBGA

Supplier device package: 96-CABGA (13.5 x 5.5 mm)

Shipment format: Tray

Mounting: Surface mount BGA

Ball count: 96-ball grid array

Size: approximately 13.5 mm x 5.5 mm body

Pin configuration: 96-ball matrix; verify ball map in the datasheet

Thermal characteristics: rated for ambient -40 to +85 C; use good PCB thermal design for heat spreading

Electrical properties: supply 2.7–3.6 V, outputs up to ±24 mA, 3-state, non-inverting transceiver

Compliance: RoHS non-compliant

Lifecycle

Lifecycle status can vary by package and region; availability changes over time

The 74ALVCH family remains widely used, but this specific BF BGA variant may have limited stock depending on demand

Functional equivalents and alternatives to consider (verify pinout, package, voltage, and timing before use):

- Texas Instruments SN74ALVCH32245 (multiple packages available)

- Nexperia 74ALVCH32245

- onsemi/Fairchild 74ALVCH32245

- Renesas/IDT 74ALVCH32245 in other package codes or suffixes

- Related alternatives with similar function but different voltage/process families: SN74LVC32245, 74ALVC32245 (check supply range and timing)

If you need exact mechanical and pin-compatible replacements or more options, contact our sales team via the Y-IC website for the latest cross-reference and availability
