Taiyo Yuden EMK212B7684MD-T

Overview of the Taiyo Yuden EMK212B7684MD-T

The Taiyo Yuden EMK212B7684MD-T is a multilayer ceramic chip capacitor (MLCC) tailored for a wide array of general-purpose and decoupling applications. With its mid-range capacitance, standard 16V rating, and X7R dielectric, this capacitor addresses the needs of engineers seeking consistency, compactness, and durability in surface-mount designs. This article provides a technical deep-dive into the EMK212B7684MD-T, guiding product engineers and procurement professionals through its essential attributes, potential deployment environments, and selection considerations.

Primary Features and Parameters of the EMK212B7684MD-T

The EMK212B7684MD-T is specified as a 0.68 µF, ±20% tolerance MLCC with a maximum working voltage of 16 volts DC. It utilizes the X7R temperature-stable ceramic dielectric, ensuring reliable capacitance performance across a broad operating temperature range typical in industrial and commercial applications. The device is housed in the industry-standard 0805 (2012 metric) SMD package, aligning with modern automated PCB assembly processes.

Key parameters summarized:

— Capacitance Value: 0.68 µF

— Capacitance Tolerance: ±20%

— Rated Voltage: 16 V DC

— Dielectric Material: X7R (temperature-stable Class II, -55 °C to +125 °C)

— Package Size: 0805 (2.0 × 1.25 mm or 2012 metric)

The combination of X7R dielectric and 16V rating positions the EMK212B7684MD-T well for robust filtering, decoupling, and signal conditioning tasks, particularly where moderate capacitance and voltage handling are required.

Typical Applications and Scenarios for Using the EMK212B7684MD-T

The Taiyo Yuden EMK212B7684MD-T is engineered to serve a variety of general electronic applications that demand reliable, compact MLCCs with mid-value capacitance. Common engineering scenarios include power supply line decoupling, noise filtering in analog and digital circuits, bulk capacitance in voltage regulator input/output stages, and signal coupling or bypassing for microcontroller and interface circuitry.

Its 0.68 µF value and X7R dielectric create a balance between energy storage and circuit stability, making it suitable for automotive electronics, industrial automation controllers, communication hardware, and consumer devices where board real estate is at a premium yet stable performance at variable temperature is essential.

Benefits and Performance Strengths of the Taiyo Yuden EMK212B7684MD-T

The EMK212B7684MD-T leverages Taiyo Yuden’s expertise in layered ceramic construction, delivering low equivalent series resistance (ESR) and high reliability over time. The X7R dielectric affords a stable capacitance (variation within ±15% over its temperature range), essential for circuits sensitive to parameter drift. Additionally, the 0805 SMD profile guarantees compatibility with high-speed pick-and-place assembly systems and automated soldering techniques, optimizing throughput and board density in mass production environments.

For design engineers, the EMK212B7684MD-T offers proven performance consistency—critical for applications requiring dependable noise suppression or ripple filtering under fluctuating operating conditions.

Packaging Details and Mounting Guidelines for the EMK212B7684MD-T

The EMK212B7684MD-T employs the universal 0805 (2012 metric) surface-mount package, measuring 2.0 mm × 1.25 mm. This size is widely adopted across industry standards, enabling straightforward integration into diverse PCB layouts, including dense multilayer arrangements common in high-reliability and miniaturized consumer assemblies. Surface-mount compatibility allows use with reflow soldering and supports automated optical inspection, minimizing manual rework and optimizing manufacturing yield.

Alternative or Compatible Models for the EMK212B7684MD-T

For engineers and procurement specialists evaluating the Taiyo Yuden EMK212B7684MD-T, it is prudent to consider form-fit-function equivalents from other suppliers to ensure second-source flexibility. Comparable MLCCs should match or exceed the following criteria: 0.68 µF capacitance, ±20% tolerance (or tighter), 16V DC rating (or higher), X7R dielectric, and 0805 (2012 metric) surface-mount profile.

Widely recognized equivalents may include offerings from leading passive component manufacturers such as Murata, Samsung Electro-Mechanics, or TDK, provided their products meet or surpass these parameters. Reviewing specific datasheets—particularly for ESR, temperature coefficient, and AEC-Q200 (if automotive)—will be essential for critical use cases.

Conclusion

Taiyo Yuden’s EMK212B7684MD-T brings together reliability, size efficiency, and consistent electrical characteristics, making it a trusted MLCC solution in diverse application segments. Its standardized 0.68 µF X7R/16V/0805 format streamlines selection and sourcing processes, while facilitating easy cross-supplier comparisons. For engineers specifying capacitors in high-mix or cost-sensitive designs, the EMK212B7684MD-T stands out as a highly competitive and technically sound component choice.
