Renesas Electronics America Inc R5F10JBCAFP#V0

Mfr. Part

R5F10JBCAFP#V0

Manufacturer

Renesas Electronics Corporation

Y-IC is a quality distributor for Renesas. We supply genuine Renesas parts and deliver the best products and services to our customers.

Detailed Description

16-bit RL78/G1C microcontroller in a 32-LQFP (7x7 mm) package with 32KB flash, 5.5KB RAM, and 2KB EEPROM. Runs up to 24MHz, supports USB, UART/USART, I2C, CSI, and includes 8-channel 8/10-bit ADC. Operates from 2.4V to 5.5V and -40°C to +85°C. Comes in tray packaging. Ideal for low-power, USB-connected embedded applications needing compact size and robust peripherals.

Key Features

Core RL78 16-bit CPU, up to 24MHz

Memory 32KB flash, 5.5KB RAM, 2KB EEPROM

I/O 22 GPIO lines

Connectivity USB device, UART/USART, I2C, CSI

Analog 8-channel ADC, 8/10-bit resolution

Oscillator Internal clock source

Peripherals DMA, PWM, WDT, LVD, POR

Supply voltage 2.4V to 5.5V

Package 32-LQFP (7x7 mm), surface mount

Series RL78/G1C, base product R5F10

Compliance RoHS3 compliant

Operating temperature -40°C to +85°C (TA)

Key Advantages

Low power RL78 architecture for battery-friendly designs

Integrated USB reduces external components and BOM cost

Wide supply range fits 3.3V and 5V systems

Small 32-pin LQFP saves board space and simplifies routing

Robust reliability with LVD, POR, and WDT

Flexible DMA for efficient data movement and lower CPU load

Mature toolchain and ecosystem from Renesas for faster development

Industrial temperature range for dependable field operation

On-chip EEPROM for nonvolatile data storage without extra memory

Internal oscillator simplifies design and reduces parts count

Packaging

Type 32-LQFP, surface-mount

Material Lead-free, RoHS3 compliant plastic (epoxy molding compound) with copper alloy leadframe and gull-wing leads

Size 7 x 7 mm body

Pin configuration 32 pins across four sides, gull-wing leads; 22 GPIO available; USB D+ and Dpins on dedicated pads (see datasheet for exact pinout)

Thermal characteristics -40°C to +85°C operating temperature; no exposed thermal pad; thermal performance depends on PCB copper area and layout

Electrical properties 2.4V to 5.5V supply, 24MHz core speed, internal oscillator, 8-channel 8/10-bit ADC, USB device interface, UART/USART, I2C, CSI

Manufacturer package code 32-LQFP (7x7)

Shipment packaging Tray

Stock availability 2568 units available (subject to change)

Lifecycle

Current status Active as per latest public information. No discontinuation notice observed. Availability can change; confirm with our sales team.

Equivalent or alternative models

- Renesas RL78/G1C family Same core and USB features; pin-compatible memory variants in 32-LQFP exist (e.g., 16KB and 64KB flash options). Suffix options like #U0 (tape and reel) and #V0 (tray) are packaging codes for the same silicon. Contact us for exact part numbers that are pin-compatible with R5F10JBCAFP#V0.

- Renesas RL78/G1C wider pin-count options 48-pin and 64-pin devices offer more I/O and peripherals if you need expansion.

- Renesas RL78/G13 family Similar performance with broader peripheral sets (not pin-compatible); good for feature upgrades without USB.

- Cross-vendor functional alternatives (not pin-compatible)

- Silicon Labs EFM8UB1 series 8-bit MCUs with USB FS

- Microchip PIC24FJ GB and PIC18F USB families 16-bit and 8-bit MCUs with USB device

- NXP LPC11Uxx Cortex-M0 MCUs with USB device

- STMicroelectronics STM32F042/STM32F072 Cortex-M MCUs with USB FS

For a precise, pin-compatible or drop-in list, please contact our sales team via our website. We will match memory size, package, and USB needs to the best alternatives in stock.

Key Application Areas

USB HID devices keyboards, mice, keypads, remote controls

USB communication adapters USB-to-UART bridges, CDC devices

PC peripherals and accessories dongles, hubs, interface modules

Consumer electronics wearables, toys, smart home accessories

Industrial sensors and controllers with USB service ports or data offload

Data loggers and portable instruments needing low power and USB connectivity

Small appliances and HMI panels with simple control and USB update

Medical and laboratory devices that require reliable, low-power control and PC connectivity
