Microchip Technology M2GL050TS-VFG400

Mfr. Part

M2GL050TS-VFG400

Manufacturer

Micrel / Microchip Technology

Y-IC is a quality distributor for Micrel / Microchip Technology. We stand behind the brand and deliver the best products, fast service, and reliable support.

Detailed Description

IGLOO2 family flash-based FPGA with 56,340 logic elements and 1,869,824 total RAM bits. 207 user I O in a compact 400-ball VFBGA 17 x 17 mm package. Wide supply range 1.14 V to 2.625 V. Surface-mount BGA for high-density designs. Commercial operating junction temperature 0 to 85 C. RoHS3 compliant. Base product number M2GL050. Supplied on tray. Quantity available 2677.

Key Features

Non-volatile flash FPGA architecture for instant-on and configuration retention without external memory

56,340 logic elements for mid-range designs

1,869,824 RAM bits for buffering, FIFOs, and on-chip data storage

207 user I O for rich connectivity and parallel interfaces

Wide supply range 1.14 V to 2.625 V for flexible power rails

IGLOO2 low-power design with very low static power

BGA package 400 balls 17 x 17 mm for compact, high-pin-count layouts

Surface mount for automated assembly and reflow

RoHS3 compliant lead-free manufacturing

Industry-standard toolchain and IP ecosystem

Key Advantages

Instant-on non-volatile architecture removes external configuration memory and speeds system startup

Low power reduces thermal load and simplifies cooling

High I O count supports multiple interfaces, wide buses, and bridging tasks

Robust reliability with flash-based configuration immune to SEU in configuration bits

Stable supply range supports common core and I O voltages

Mature IGLOO2 platform with strong documentation and long-term availability

Compact BGA footprint enables space-constrained designs without sacrificing pin count

Packaging

Type 400-ball VFBGA for very fine pitch grid array interconnect

Material organic BGA substrate with epoxy mold compound and lead-free SAC solder balls RoHS3 compliant

Size 17 x 17 mm body outline small footprint yet high pin density

Pin configuration 400 balls total 207 user I O balance are power ground configuration JTAG clock and auxiliary pins refer to pinout guide for exact ball map

Mounting surface mount compatible with standard lead-free reflow profiles

Thermal characteristics commercial junction temperature 0 to 85 C use adequate copper planes and vias under BGA for heat spreading follow datasheet for thermal design

Electrical properties supply 1.14 V to 2.625 V stable low-power operation controlled impedance I O banks supported per family guidelines see datasheet for bank standards and limits

Shipment packaging tray for safe handling and assembly line use

Lifecycle

Status Active in production not nearing discontinuation per current Microchip IGLOO2 family guidance

Equivalent and alternative models

- Same density alternatives in different packages and options M2GL050 variants in 400 LFBGA and other BGA footprints

- SmartFusion2 SoC FPGA family with similar logic density plus integrated ARM M2S050 for designs needing an embedded MCU

- PolarFire family MPF050 for applications needing lower power at higher performance and advanced security

- Lower and higher density IGLOO2 options M2GL010 M2GL025 M2GL090 to match resource needs

- Note package pinout speed grade and temperature range vary verify compatibility against your board and constraints

If you need a direct drop-in or detailed cross list contact Y-IC sales via our website and we will provide precise part-number mapping and availability

Key Application Areas

Industrial control PLC motion control motor drivers and sensor fusion

Communications and networking bridges protocol conversion and packet processing

Embedded computing I O expansion memory controllers and system glue logic

Security and safety instant-on control logic secure configuration and tamper-resistant designs

Test and measurement high-speed data capture timing and triggering

Consumer and medical devices compact low-power logic with many I O interfaces

Datasheet

Y-IC provides the most authoritative datasheet for this product on our website. Download the latest IGLOO2 M2GL050TS-VFG400 datasheet from this page to get full pin maps electrical limits timing and design guidelines.

Request for Quotation Now

Limited Time Offer Get a Quote on Y-IC now for M2GL050TS-VFG400

Fast response and competitive pricing Learn More and secure your supply today
