Texas Instruments LP3986TL-2525/NOPB

Mfr. Part

Base product number LP3986

Manufacturer

Luminary Micro / Texas Instruments (TI)

Y-IC is a quality distributor for TI and Luminary Micro. We supply genuine parts, deliver fast, and support you with expert service and the best products.

Detailed Description

Dual low-dropout (LDO) linear voltage regulator

Fixed 2.5 V outputs, positive configuration

Up to 150 mA per LDO output

Low dropout 0.1 V at 150 mA for efficient regulation

High PSRR 60 dB at 1 kHz and 50 dB at 10 kHz for clean power

Enable control for easy power management

Wide operating temperature -40°C to +125°C

Surface-mount wafer-level package, ultra-small footprint

RoHS3 compliant, lead-free NOPB version

Main category Integrated Circuits (ICs); subcategory PMIC – Voltage Regulators – Linear, LDO Regulators

Key Features

Two regulators in one chip to power dual 2.5 V rails

6 V max input voltage range

Low quiescent current ~130 µA (typical)

Max supply current ~320 µA (typical under load)

Strong ripple rejection for noise-sensitive analog/RF loads

Built-in protections: over-current, over-temperature, short-circuit

Single enable pin for simple on/off control

Stable operation and straightforward PCB integration

Key Advantages

Saves board space with an 8-ball DSBGA package (1.56 x 1.56 mm)

Extends battery life via low dropout and low quiescent current

Improves signal integrity in audio, RF, and precision analog through high PSRR

Increases system reliability with comprehensive protection features

Simplifies power sequencing with enable control

Operates reliably across industrial temperature range

Packaging

Supply format Tape and Reel (TR) for automated SMT assembly

IC package 8-DSBGA (Supplier Device Package 8-DSBGA, body size 1.56 x 1.56 mm); also referenced as 8-WFBGA, DSBGA

Ball count and layout 8-ball grid array; compact pinout suitable for dense layouts

Mounting type Surface Mount

Materials lead-free, RoHS3 compliant; wafer-level chip-scale construction with solder balls

Pin functions typical for dual LDOs include VIN, VOUT1, VOUT2, GND, EN; see datasheet for exact ball map and naming

Thermal characteristics thermal performance depends on PCB copper and layout; design for good heat spreading; consult datasheet for RθJA/RθJC and layout guidance

Electrical properties input voltage up to 6 V; fixed 2.5 V outputs; dropout 0.1 V at 150 mA; PSRR 60–50 dB in the 1–10 kHz band; output current up to 150 mA per regulator; low quiescent current ~130 µA; protection features include OCP, OTP, and short-circuit
