Texas Instruments LM317HVH/NOPB

Mfr. Part

LM317HVH/NOPB

Manufacturer

Luminary Micro Texas Instruments

Y-IC is a quality distributor for Texas Instruments. We supply genuine TI parts and provide the best products and services to our customers.

Detailed Description

High‑voltage adjustable linear regulator, positive output, TO‑3 metal can package. Delivers up to 1.5 A with input up to 60 V and adjustable output from 1.25 V to 57 V. Through‑hole mounting. RoHS3 compliant. Operating temperature 0 to 125°C. Family base number LM317. Supplied in bulk packaging. In stock quantity 2968.

Key Features

Adjustable output 1.25 V to 57 V

Input voltage up to 60 V

Output current up to 1.5 A

Positive regulator, single channel

Low quiescent current around 12 mA

PSRR about 80 dB to 65 dB at 120 Hz

Built‑in protections: over‑current, over‑temperature, short‑circuit

Stable operation with proper bypassing and load

Simple two‑resistor setpoint for output voltage

Through‑hole TO‑3 form factor for power designs

RoHS3 compliant

Key Advantages

Wide input and output ranges cover many industrial rails

Robust TO‑3 metal can gives excellent heat dissipation and mechanical strength

Proven LM317 architecture with strong line and load regulation

Easy design‑in with minimal external parts

Reliable protections reduce failure risk

Suitable for harsh environments and high power applications

Packaging

Type: TO‑3 metal can (Supplier Device Package TO‑3; related family packages may reference TO‑205AD or TO‑39‑3 metal can)

Material: all‑metal case for high thermal conductivity and durability

Size: standard TO‑3 outline compatible with common heatsinks and mounting hardware

Pin configuration: 3 terminals total

- Pin 1 Adjust

- Pin 2 Output

- Case tab Input

Mounting: through‑hole, two mounting holes for secure heatsink attachment

Thermal characteristics: designed for direct heatsink mounting and low thermal resistance when properly greased and fastened; supports sustained 1.5 A with appropriate thermal management

Electrical properties: positive adjustable regulator, quiescent current about 12 mA, PSRR roughly 80–65 dB at 120 Hz, protection against over‑current, over‑temperature, and short‑circuit

Shipment: bulk

Lifecycle

Status: Active and widely supported; not nearing discontinuation based on current industry availability

Equivalent and alternative models

- Texas Instruments LM317K (same family, TO‑3 package; verify voltage ratings vs HV requirement)

- ON Semiconductor LM317HVK or LM317HV (high‑voltage variants; check package and pinout)

- STMicroelectronics L317K or L317HVT (comparable adjustable regulators; verify voltage and current specs)

- Analog Devices LT317A (functionally similar adjustable regulator; verify package and current capability)

- Microchip MIC29152 adjustable LDO 1.5 A (functional alternative; not pin‑compatible)

- Note: Always verify pin configuration, maximum input voltage, thermal performance, and dropout requirements before substitution

If you need a drop‑in cross or more options, please contact our sales team via the Y-IC website for detailed guidance

Key Application Areas

Adjustable bench and lab power supplies

Industrial control rails and instrumentation

Post‑regulation after switching supplies for low ripple outputs

Battery chargers and current‑limited supplies

LED driver constant‑current stages using sense resistors

Telecom and networking equipment analog rails

Automotive and transportation auxiliary supplies with proper thermal design
