Littelfuse Inc. 56200001009

Summary of Littelfuse 56200001009 Fuse Holder Series

The Littelfuse 56200001009 is a specialized fuse holder designed to support TE5/TR5 type fuses in printed circuit board (PCB) applications. As part of the Littelfuse 562/564 Series, this component offers engineers a dependable solution for integrating circuit protection in a variety of electronic designs. The fuse holder accommodates a single circuit and is intended for radial through-hole mounting, making it particularly suited for robust configurations and easy replacement in the field. Its rated voltage of 250V and maximum current of 6.3A position it as a versatile choice for medium-power circuit protection.

Main Attributes and Technical Details of Littelfuse 56200001009 Fuse Holder

The 56200001009 fuse holder stands out due to its compatibility with TE5/TR5 style fuses and its optimized footprint for PCB assembly. Key specifications include:

Maximum voltage rating: 250V

Maximum current rating: 6.3A

Circuit configuration: Single circuit

Mounting style: Radial, through-hole

Series: 562 (also related to 564 Series for similar applications)

These details align with the requirements of many standard and custom PCB designs, especially in equipment where field-replaceability and clear layout are crucial.

Physical and Electrical Properties of the Littelfuse 56200001009 Fuse Holder

Designed for reliability and ease of installation, the Littelfuse 56200001009 fuse holder features robust mechanical properties. With dimensions clearly set out in Littelfuse's documentation (units in millimeters), the holder ensures compatibility with standard PCB layouts and automates alignment during assembly. Electrical characteristics emphasize safe operation under rated voltage and current levels, minimizing risks of overheating or contact failure. The physical construction supports stable fuse retention, while the radial design aids in straightforward soldering and replacement.

Guidelines for Soldering and Installing the Littelfuse 56200001009 Fuse Holder

Proper mounting and soldering are critical for the effective performance and longevity of the Littelfuse 56200001009 fuse holder. The recommended assembly methods include wave soldering and hand soldering. For hand soldering, a solder iron temperature of 350°C (±5°C) and a heating limit of 5 seconds are suggested. It is important to note that this component is not recommended for infrared (IR) or convection reflow processes, indicating that engineering teams need to align their assembly methods accordingly. These parameters help ensure consistent joint quality and minimize potential component stress.

Use Cases and Integration Recommendations for Littelfuse 56200001009 Fuse Holder

The Littelfuse 56200001009 fuse holder is ideal for applications requiring mid-range circuit protection and simple fuse access, such as industrial control boards, consumer electronics, and power conversion systems. Its single-circuit design suits straightforward protection schemas, allowing engineers to configure protections for sensitive loads or sub-circuits. When integrating, designers should consider PCB layout space, fuse specifications, and accessibility for future maintenance or fuse replacement. Its mechanical reliability and electrical ratings help streamline product compliance with safety standards.

Alternative or Substitute Options for Littelfuse 56200001009 Fuse Holder

For users evaluating alternatives to the Littelfuse 56200001009, the Littelfuse 564 Series presents a comparable solution for TE5/TR5 type fuse holders with slightly different mounting or mechanical configurations. Selection between the 562 and 564 should be based on specific PCB layout constraints and required mechanical form factors. Engineers may also compare performance attributes and physical dimensions with other industry-standard fuse holders for TE5/TR5 fuses, ensuring compatibility and reliability in their chosen application.

Conclusion

: Selecting the right Littelfuse 56200001009 fuse holder for PCB projects

The Littelfuse 56200001009 fuse holder delivers a dependable, specification-driven option for circuit protection in PCB-based designs, balancing mechanical strength, ease of assembly, and electrical safety. With a clear understanding of its technical characteristics, mounting requirements, and possible alternatives, product selection engineers and procurement professionals are well equipped to choose the best solution for each project’s protection needs. By ensuring proper handling and assembly as outlined, teams can realize stable, serviceable protection for a wide range of electronic applications.
