Analog Devices Inc./Maxim Integrated MAX8902AATA+T

Mfr. Part

MAX8902AATA+T

Manufacturer

Analog Devices Maxim Integrated

Y-IC is a quality distributor for Analog Devices Maxim Integrated. We supply original parts with reliable lead time and professional support

Detailed Description

Single-channel positive LDO regulator with programmable output. Delivers up to 500 mA with very low dropout and high PSRR for clean power to noise-sensitive loads. Wide output adjust range via external resistors. Compact 2 x 2 mm 8-pin TDFN with exposed pad for strong thermal performance. Ideal for battery-powered and portable systems that need low noise, high efficiency at light load, and robust protection

Key Features

LDO linear regulator positive output

Programmable output 1.5 V to 4.7 V via external resistors

Output current up to 500 mA

Low dropout 120 mV at 500 mA

High PSRR 92 dB at 5 kHz falling to 62 dB at 100 kHz

Wide input voltage up to 5.5 V

Low quiescent current about 120 µA typical and 160 µA max supply current

Enable control for easy on off sequencing

Protections over temperature reverse polarity short circuit soft start

One regulator channel

Industrial temperature range minus 40°C to plus 125°C

RoHS3 compliant

Key Advantages

Very clean output for RF analog and high performance digital rails thanks to high PSRR

Low dropout keeps efficiency high and extends battery life

Small 2 x 2 mm DFN saves PCB area in space constrained designs

Robust protections improve system reliability and simplify fault handling

Simple control and programmable output reduce BOM and speed design-in

Wide temperature range supports harsh environments

Packaging

Delivery format Tape and Reel TR for automated assembly

Device package 8-TDFN-EP 2 x 2 mm also known as 8-WFDFN Exposed Pad supplier device package 8-TDFN-EP 2 x 2

Body material RoHS3 compliant molded epoxy with exposed copper thermal pad halogen free processes typically supported

Approximate body size 2.0 mm x 2.0 mm low profile height refer to datasheet for exact mechanical dimensions and tolerances

Pin configuration 8 leads plus an exposed thermal pad consult the datasheet for exact pinout and recommended land pattern

Mounting type Surface mount reflow capable follow JEDEC reflow profile and moisture handling per datasheet

Thermal characteristics Exposed pad must be soldered to a solid copper area preferably tied to ground for low thermal resistance observe board level thermal derating guidance in the datasheet

Electrical properties summary output current 500 mA dropout 120 mV at 500 mA PSRR 92 dB at 5 kHz to 62 dB at 100 kHz quiescent current about 120 µA typical supply current up to 160 µA protections include over temperature reverse polarity short circuit and soft start
