STMicroelectronics STM32MP151FAD1

Mfr. Part

STM32MP151FAD1

Manufacturer

STMicroelectronics. Y-IC is a quality distributor of STMicroelectronics and we will provide you with the best products and services

Detailed Description

High-performance microprocessor unit based on ARM Cortex-A7 up to 800 MHz with an ARM Cortex-M4 up to 209 MHz for real-time tasks. Belongs to the STM32MP1 series. Designed for Linux-capable embedded systems with rich connectivity, display control, security features, and external DDR memory support. RoHS3 compliant. Single-core A7 with 32-bit bus width, integrating extensive interfaces for industrial and consumer applications

Key Features

Core processors ARM Cortex-A7 up to 800 MHz and ARM Cortex-M4 up to 209 MHz

Single-core A7 architecture with 32-bit bus

External memory controllers for DDR3, DDR3L, LPDDR2, LPDDR3

Ethernet 10 or 100 Mbps one MAC

USB connectivity USB 2.0 two ports and USB 2.0 OTG with integrated PHY three ports

Graphics acceleration enabled plus LCD display controller

Display and interface controllers HDMI-CEC and LCD-TFT

Security ARM TrustZone support

Additional interfaces CAN Ethernet I2C MMC SD SDIO SPDIF SPI UART USB

I O voltage support 2.5 V and 3.3 V

Operating junction temperature range minus 20 to 105 degrees Celsius

Package 257 TFBGA 10 x 10 mm surface mount

Series STM32MP1

Mounting type surface mount and tray packing

Key Advantages

Dual-domain compute with A7 for Linux applications and M4 for deterministic real-time control on one chip

Flexible external DDR memory options for cost and performance tuning

Rich peripheral set reduces need for extra chips and simplifies board design

Mature STM32 ecosystem tools and strong community support

Long-term availability typical of STMicroelectronics industrial products

Low power modes and scalable performance for power-sensitive designs

Built-in security isolation with ARM TrustZone for safer firmware and data handling

Packaging

Package type thin fine pitch ball grid array TFBGA

Size 10 mm by 10 mm body

Ball count 257 balls full grid pattern

Mounting surface mount technology SMT

Delivery format tray

Materials mold compound with solder ball array typical for BGA packages

Pin configuration 257-ball map per ST datasheet verify ball assignments and alternate functions before layout

Thermal characteristics junction temperature minus 20 to 105 degrees Celsius thermal performance depends on PCB copper area and airflow use thermal analysis during design

Electrical properties I O voltage levels 2.5 V and 3.3 V external DDR supply per selected memory type other rails per datasheet implement proper decoupling and power sequencing

Lifecycle

Status active and in production not nearing discontinuation based on current industry availability

Equivalent and alternative models within STM32MP1 family depending on features and package

- STM32MP151 variants such as STM32MP151AAD1 and STM32MP151FAD3 similar CPU and peripherals with different temperature grades or options

- STM32MP153 family adds more multimedia and interface options while keeping A7 plus M4 architecture

- STM32MP157 family adds enhanced graphics including 3D GPU and additional interfaces for advanced HMI

Pin compatibility and peripheral availability vary across variants and packages always verify with the official datasheet and hardware design resources

If you need exact drop-in equivalents or current lead times contact our sales team via our website for detailed guidance

Key Application Areas

Industrial HMI panels and control terminals

IoT gateways and edge computing nodes

Smart home hubs and building automation controllers

Motor control with real-time loops on M4 and Linux UI on A7

Medical devices and diagnostics interfaces

Retail POS terminals and kiosks

Connected sensors and data loggers with secure cloud connectivity

Audio and multimedia endpoints with LCD display and HDMI-CEC integration

Datasheet

Our website hosts the most authoritative and up-to-date datasheet for STM32MP151FAD1. We strongly recommend downloading it from this page to get exact pin maps electrical limits boot options and software recommendations

Request for Quotation Now

Get a Quote on our website today. Learn More about availability and lead times. Limited Time Offer secure your allocation now with Y-IC for the best service and support
